Meets API and OCMA performance standards
Korvanto Bentonite
Korvanto Bento Drilling
API & OCMA Drilling-Grade Bentonite
Export Ready
Overview
Product Overview
KORVANTO BENTO DRILL™ is a range of high-quality drilling-grade bentonite products developed for oil & gas water well HDD geothermal piling and geotechnical drilling applications. Available in API and OCMA grades these products provide excellent viscosity gel strength borehole stability fluid loss control and cuttings suspension for efficient drilling operations worldwide.
Performance
Key Benefits
High Yield
Excellent Gel Strength
Low Fluid Loss
Borehole Stabilization
Efficient Cuttings Suspension
Easy Mixing
Thermal Stability
Consistent Batch Quality
Technical Data
Representative Technical Specifications
KORVANTO BENTO DRILL API — API Grade Bentonite
| Parameter | Representative Value |
|---|---|
| Viscometer Dial Reading @ 600 rpm | Min. 30 |
| Yield Point / Plastic Viscosity Ratio | Max. 3 |
| Filtrate Volume | Max. 15 cm³ |
| Residue >75 Micron | Max. 4.0% |
Representative values shown above. Full Technical Data Sheet (TDS) Certificate of Analysis (COA) and additional documentation are available upon request.
KORVANTO BENTO DRILL OCMA+ — OCMA Plus Grade Bentonite
| Parameter | Representative Value |
|---|---|
| Viscometer Dial Reading @ 600 rpm | Min. 30 |
| Yield Point / Plastic Viscosity Ratio | Max. 6 |
| Filtrate Volume | Max. 16 cm³ |
| Residue >75 Micron | Max. 2.5% |
Representative values shown above. Full Technical Data Sheet (TDS) Certificate of Analysis (COA) and additional documentation are available upon request.
KORVANTO BENTO DRILL OCMA — OCMA Grade Bentonite
| Parameter | Representative Value |
|---|---|
| Viscometer Dial Reading @ 600 rpm | Min. 30 |
| Yield Point / Plastic Viscosity Ratio | Max. 8 |
| Filtrate Volume | 16–18 cm³ |
| Liquid Limit | 400–600 |
| Particle Size / Fineness | 85% through 200 B.S. |
Representative values shown above. Full Technical Data Sheet (TDS) Certificate of Analysis (COA) and additional documentation are available upon request.
Custom grades and tailored specifications can be supplied based on drilling conditions and customer requirements.
Industry Use
Applications
Grades
Available Grades
KORVANTO BENTO DRILL API
API Grade Bentonite
KORVANTO BENTO DRILL OCMA+
OCMA Plus Grade Bentonite
KORVANTO BENTO DRILL OCMA
OCMA Grade Bentonite
Bespoke Supply
Custom Grade
Custom Manufacturing Options
Korvanto supplies bento drilling according to customer requirements including:
Discuss Custom Specs →Particle Size Distribution
Custom Specifications & Grades
Application-Specific Formulations
Quality & Purity Requirements
Custom Packaging
Export Documentation Support
Export Supply
Packaging Options
Compliance
Quality Assurance
Specification-Focused Sourcing
Quality Verification Support
Batch Consistency Monitoring
Third-Party Testing Available Upon Request
Product Support
Frequently Asked Questions
What is drilling grade bentonite
Drilling grade bentonite is a specially processed bentonite designed to prepare drilling fluids used in oil & gas water well horizontal directional drilling (HDD) geothermal and geotechnical drilling. It helps stabilize boreholes suspend drill cuttings control fluid loss and improve drilling efficiency.
What drilling applications is KORVANTO BENTO DRILL suitable for
Korvanto BENTO DRILL is suitable for a wide range of drilling applications including:
Oil & Gas Drilling
Water Well Drilling
Horizontal Directional Drilling (HDD)
Geothermal Drilling
Geotechnical Investigation
Mineral & Core Exploration
Borehole Stabilization
The appropriate grade depends on drilling conditions and project requirements.
What is the difference between API and OCMA drilling bentonite
API bentonite is manufactured to meet the requirements of API Specification 13A commonly used in oil and gas drilling operations. OCMA bentonite is produced in accordance with OCMA specifications and is widely used for water well drilling piling HDD and general drilling applications. The choice depends on the drilling method fluid performance requirements and customer specifications.
Does Korvanto offer API and OCMA grades
Yes. Korvanto offers a range of drilling bentonite products including API Grade OCMA Grade and enhanced drilling grades. Customized drilling formulations can also be supplied based on customer requirements and application conditions.
What are the main functions of drilling bentonite
Drilling bentonite performs several important functions including:
Stabilizing borehole walls
Suspending and transporting drill cuttings
Controlling fluid loss
Cooling and lubricating drill bits
Forming a low-permeability filter cake
Supporting efficient drilling operations
Can drilling bentonite be customized
Yes. Korvanto can supply customized drilling bentonite grades based on customer specifications drilling conditions viscosity requirements and application-specific performance requirements.
What technical documents are available
Technical documentation can be provided upon request including:
Technical Data Sheet (TDS)
Certificate of Analysis (COA)
Safety Data Sheet (SDS/MSDS)
Other export documentation as required
What packaging options are available
Korvanto BENTO DRILL is available in:
25 kg Bags
50 kg Bags
Jumbo Bags (FIBC)
Palletized Loads
Bulk Supply Options
Customized Export Packaging
Packaging can be tailored to customer and destination requirements.
Can KORVANTO BENTO DRILL be used for Horizontal Directional Drilling (HDD)
Yes. Selected drilling grades are suitable for HDD applications where drilling fluid performance borehole stability and efficient cuttings transport are essential. The recommended grade depends on soil conditions and project requirements.
Is KORVANTO BENTO DRILL suitable for water well drilling
Yes. Korvanto BENTO DRILL is widely used in water well drilling applications to improve drilling fluid performance stabilize boreholes and facilitate efficient removal of drill cuttings.
What factors should be considered when selecting a drilling bentonite
The appropriate drilling bentonite depends on several factors including drilling method formation type borehole conditions required viscosity fluid loss characteristics and applicable industry specifications. Korvanto can assist in selecting the most suitable grade based on project requirements.
What is the shelf life of drilling bentonite
When stored in a clean dry environment and protected from moisture drilling bentonite maintains its performance characteristics for an extended period. Proper storage in sealed packaging helps preserve product quality until use.
Can Korvanto supply bulk export quantities
Yes. Korvanto supplies drilling bentonite for both domestic and international markets with flexible packaging options and export logistics support for containerized and bulk shipments.
Is third-party testing available
Yes. Independent third-party testing can be arranged upon customer request prior to dispatch subject to project requirements and agreed inspection procedures.
How can I request a quotation or Technical Data Sheet (TDS)
Simply contact the Korvanto export team through our website email WhatsApp or Request a Quote form. Please share your drilling application preferred grade (API OCMA or customized) quantity destination country and any technical requirements so that we can recommend a suitable product and provide the relevant documentation.
Get Started
Request TDS / Request Quote
Share your grade requirements destination country and documentation needs. Our export team will provide a Technical Data Sheet certificate support and a tailored quotation for Korvanto Bento Drilling.
